CO2 incubator suitable for mammalian cell culture, where an elaborate pH level shall be achieved by controlling a CO2 level (0~20%)
Providing stable culture environment through constant and even temperature distribution and precisely controllable CO2 gas
Water-Jacketed CO2 Incubator can maintain temperature by surrounding the chamber with hot walls generated from the heated water. The heated water circulates and radiates heat around the inner chamber which maintains constant temperature.
Water-Jacketed CO2 Incubator can hold the chamber temperature much longer when power is lost. The incubator will also be able to recover temperature much faster after a power failure and also gets back more quickly after door has been opened or changes in temperature settings
CO2 Incubator uses Direct Heat / Air Jacketed Heating System which surrounds the inner chamber walls combined with natural convection airflow that radiate wall heat through thermal conduction.This technique achieves accurate, uniform and highly responsive temperature control within the chamber.
Precise temperature control is available in unit of 0.1°C Precise CO2 control is available in unit of 0.1% at 5% set
Auto-tuning is applicable depending on temperature and humidity at site
Measurement and control of CO2 concentration with high accuracy is possible through Non-dispersive dual beam infrared ray sensor (NDIR).
A wide 240 x 64 graphic in LCD screen makes user check the parameter at a glance. Touch panel along with LCD screen is equipped for easy setting of parameter Change of font size in the PV value depending on set menus.
Interior : The chamber is made of Stainless Steel (SUS 304) leads hygienic condition inside.
Exterior : The Exterior is made of steel plates (Cr41) Anti-corrosion liquid / powder coating steel(Cr 41).
Temperature is controlled by heating and circulating internal air, which enables to achieve to the set temperature quickly
The water jacket system is a water type system to insert water of high specific heat into a CO2 incubator chamber jacket with a view to maintaining its temperature.
Circulation fans are equipped to minimize temperature deviations inside the chamber.
4 Perforated stainless shelves of adjustable height to put experiment objects on in multiple tiers.
The door is equipped with silicone gasket seal to minimize the injection of exterior air into the interior
Inside door fabricated of tempered glass to observe the inside easily.
Multi functional alarm warning device and an over-heating prevention element.
Aesthetic design easy to open by using a door side.
O2 can also be controlled along with CO2 in option model
|
Model No. |
4181A |
4182W |
|
Inner Dimension (W x D x H)mm |
540x500x680 |
|
|
Outer Dimension (W x D x H)mm |
653x639x965 |
|
|
Capacity |
180L |
180L |
|
Water Jacket |
--- |
36L |
|
Controller |
Standard : Digital PID controller(240x64 Graphic LCD, Touch Button) |
|
|
Inside Material |
Stainless steel plate 304 |
|
|
Outside Material |
Epoxy powder coated steel plate |
|
|
Shelf |
Perforated stainless shelves 4EA (Total 10EA available) |
|
|
Temperature Range |
Ambient +5°C ~ 50°C |
|
|
Temperature Accuracy |
± 0.1°C |
|
|
Sensor Type |
PT100W |
|
|
Temperature Control |
Forced convection(Direct Heating) |
|
|
CO2 Range |
0~20% |
|
|
CO2 Accuracy |
± 0.1% at 5% |
|
|
CO2 Sensor |
Dual beam NDIR sensor |
|
|
CO2 Inlet Pressure |
0.2 Mpa 5L/min |
|
|
Humidification |
Up to 95% RH at 37°C |
|
|
Power |
AC 220~230V, 50/60Hz, 1Phase |
|
|
Power Consumption |
880W |
|
|
Safety |
Over heat protector, Fuse installed noise filter |
|
|
Weight |
115 kg |
|
